KAWASAKI

Приборная панель с ЖК дисплеем

Sporty instrument panel features a large analogue tachometer and multi-function LCD screen. The design is based on that of the Ninja ZX-6R, but features original font and colouring. Functions include: speedometer, tachometer, fuel gauge, odometer, clock, dual trip meters, and warning lamps.

Регулируемое ветровое стекло

Windscreen has three available positions spanning approximately 20° and ranging from sporty to maximum wind protection. Adjustment can be done by hand (no tools required) by depressing the release button below the instrument panel. (Windscreen adjustment should be done with the bike stopped.)

Объемный топливный бак вместимостью 19 литров

19 litre fuel tank offers a substantial touring range. Dynamic fuel tank design with tall upper surface features supersport-style flared edges with a trim shape at the rear, a shape that is easy to grip with the knees.

Дополнительный отвод воздуха

With the airbox nestled between the frame beams, intake air can be affected by engine heat. The Cool Air system routes cool air to the airbox from ducts at the front of the side fairings, minimising performance loss due to heated intake air. This should not be confused with Ram Air, where force-fed air becomes pressurised in the airbox.

Расслабленная туристическая посадка

Relatively upright position (compared to supersport models) offers both control and comfort. (Rider triangle is essentially the same as that of the Z1000, with grips moved about 10 mm inward).

Полностью обновленный двигатель

Liquid-cooled, DOHC, 16-valve 1,043 cm3 In-line Four offers impressive power (101.5 kW (138 PS)) and strong torque


Задняя подвеска с горизонтальным креплением рычага

Rear suspension positions the shock unit and linkage above the swingarm. The rear shock features rebound and preload adjustability. A cam-style preload adjuster facilitates making adjustments to suit 2-up riding or luggage.

Мощные тормоза

At the front, 300 mm petal brake discs are gripped by opposed 4-piston radial-mount calipers. Caliper piston size is 30 mm. Radial-pump front brake master cylinder also contributes to the superb control and feel offered by the calipers.

Светодиодный фонарь

LED taillight design features red LED bulbs and a red transparent lens.

Передняя вилка перевернутого типа

41 mm inverted front fork features stepless compression and rebound damping and spring preload adjustability.
Settings offer both sporty performance (contributing to light handling on the street and in the hills) and comfort.

Стильная и функциональная выхлопная система

The exhaust system features a 4-into-2-pre-chamber-into-2 layout. Silencer end-caps create a quad-style image.
